Performance：
Total steel-welded structure and stress elimination by vibration , High mechanical strength and good rigidity
Hydraulic top-drive , stepless pressure adjustment and high quality sealing rings imported from overseas to ensure the machine tools reliability
Mechanical stop and steel torsion bar to maintain synchronization and high precision
The stroke and distance of the backgauge is adjusted by the motor and is well adjusted by hand , the adjustment is displayed by digital meters
Deflection compensation device is provided for the upper die and or for the lower die if the operation pressure is 250T or above

Safe fence and the electric interlocker have been designed for the machine to ensure the operation safety

Specification	Nominal Pressure	Length of working table	Throat dephts	Ram Stroke	Number of Stroke	Motor power
	KN	mm	mm	mm	m/min-1	KW
WC67Y/K-40/2200	400	2200	200	100	11	4
WC67Y/K-40/2500	400	2500	200	100	11	4
WC67Y/K-50/2500	500	2500	200	100	11	5.5
WC67Y/K-63/2500	630	2500	250	100	10	5.5
WC67Y/K-63/3200	630	3200	250	100	10	5.5
WC67Y/K-80/2500	800	2500	320	150	8	7.5
WC67Y/K-80/3200	800	3200	320	150	8	7.5
WC67Y/K-100/2500	1000	2500	320	150	8	7.5
WC67Y/K-100/3200	1000	3200	320	150	8	7.5
WC67Y/K-100/4000	1000	4000	400	150	8	7.5
WC67Y/K-125/2500	1250	2500	320	150	8	7.5
WC67Y/K-125/3200	1250	3200	320	150	8	7.5
WC67Y/K-125/4000	1250	4000	400	150	8	7.5
WC67Y/K-160/3200	1600	3200	400	180	8	11
WC67Y/K-160/4000	1600	4000	400	180	8	11
WC67Y/K-160/5000	1600	5000	400	180	7	11
WC67Y/K-160/6000	1600	6000	400	200	7	15
WC67Y/K-200/3200	2000	3200	400	200	7	15
WC67Y/K-200/4000	2000	4000	400	200	7	15
WC67Y/K-200/6000	2000	6000	400	200	7	15
WC67Y/K-250/3200	2500	3200	400	200	7	18.5
WC67Y/K-250/4000	2500	4000	400	200	7	18.5
WC67Y/K-250/6000	2500	6000	400	250	7	18.5
WC67Y/K-300/3200	3000	3200	400	250	7	22
WC67Y/K-300/4000	3000	4000	400	250	7	22
WC67Y/K-300/6000	3000	6000	400	250	7	30
WC67Y/K-300/7000	3000	7000	400	250	7	30
WC67Y/K-400/6000	4000	6000	400	250	7	30
WC67Y/K-500/6000	5000	6000	400	300	7	37
WC67Y/K-600/6000	6000	6000	420	300	7	37
